| Description: |
24 port Gigabit Ethernet Industrial Workgroup switch (20 x GE TX Ports, 4 x GE SFP combo ports), managed, software Layer 2 Professional, Store-and-Forward-Switching, IPv6 Ready, fanless design |
| Port type and quantity: |
24 ports in total; 20 x (10/100/1000 BASE-TX, RJ45) and 4 Gigabit Combo ports (10/100/1000 BASE-TX, RJ45 or 100/1000 BASE-FX, SFP) |
| Life Cycle: |
Limited Availability/Passive - the product is entering End of Life |
| Last Order Date: |
2023-12-31 |
| Last Delivery Date: |
2024-06-30 |
| Power supply/signaling contact: |
1 x plug-in terminal block, 2-pin, output manual or automatic switchable (max. 1 A, 24 V DC bzw. 24 V AC) |
| V.24 interface: |
1 x RJ11 socket, serial interface for device configuration |
| USB interface: |
1 x USB to connect auto-configuration adapter ACA21-USB |
| Twisted pair (TP): |
0-100 m |
| Single mode fiber (SM) 9/125 µm: |
see SFP module M-FAST SFP-MM/LC and SFP module M-SFP-SX/LC |
| Single mode fiber (LH) 9/125 µm (long haul transceiver): |
see SFP FO module M-FAST SFP-SM+/LC |
| Multimode fiber (MM) 50/125 µm: |
see SFP module M-FAST SFP-MM/LC and SFP module M-SFP-SX/LC |
| Multimode fiber (MM) 62.5/125 µm: |
see SFP module M-FAST SFP-MM/LC and SFP module M-SFP-SX/LC |
| Line - / star topology: |
any |
| Ring structure (HIPER-Ring) quantity switches: |
50 (reconfiguration time 0.3 sec.) |
| Operating Voltage: |
100-240 V AC, 50-60 Hz |
| Power output in BTU (IT)/h: |
119 |
| Redundancy functions: |
HIPER-Ring, MRP, MSTP, RSTP - IEEE802.1D-2004, MRP and RSTP gleichzeitig, Link Aggregation |
| Switching: |
Disable Learning (hub functionality), Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Egress Broadcast Limiter per Port, Flow Control (802.3X), Jumbo Frames, VLAN (802.1Q), GARP VLAN Registration Protocol (GVRP), Double VLAN Tagging (QinQ), Voice VLAN, GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier (v1/v2/v3) |
| Redundancy: |
Advanced Ring Configuration for MRP, HIPER-Ring (Manager), HIPER-Ring (Ring Switch), Fast HIPER-Ring, Link Aggregation with LACP, Media Redundancy Protocol (MRP) (IEC62439-2), Redundant Network Coupling, RSTP 802.1D-2004 (IEC62439-1), MSTP (802.1Q), RSTP Guards, RSTP over MRP |
| Management: |
Dual Software Image Support, TFTP, LLDP (802.1AB), LLDP-MED, SSHv1, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, Telnet |
| Diagnostics: |
Management Address Conflict Detection, Signal Contact, Device Status Indication, LEDs, Syslog, Port Monitoring with Auto-Disable, Link Flap Detection, RMON (1,2,3,9), Port Mirroring 1:1, Port Mirroring 8:1, Port Mirroring N:1, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog |
| Configuration: |
AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30), Automatic Configuration Undo (roll-back), BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port, AutoConfiguration Adapter ACA21/22 (USB), HiDiscovery, DHCP Relay with Option 82, Command Line Interface (CLI), CLI Scripting, Full-featured MIB Support, Web-based Management, Context-sensitive Help |
| Security: |
IP-based Port Security, MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, RADIUS VLAN Assignment, Multi-Client Authentication per Port, MAC Authentication Bypass, Access to Management restricted by VLAN, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, SNMP Logging, Local User Management, Remote Authentication via RADIUS |
| Time synchronisation: |
PTPv2 Transparent Clock two-step, PTPv2 Boundary Clock, Buffered Real Time Clock, SNTP Client, SNTP Server |
| Industrial Profiles: |
EtherNet/IP Protocol, PROFINET IO Protocol |
| Miscellaneous: |
Manual Cable Crossing |
| Operating temperature: |
0-+50 °C |
| Relative humidity (non-condensing): |
10-95 % |
| Dimensions (WxHxD): |
448 mm x 44 mm x 345 mm |
| Mounting: |
19" control cabinet |
| IEC 60068-2-6 vibration: |
3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min; 1 g, 8.4–150 Hz, 10 cycles, 1 octave/min |
| IEC 60068-2-27 shock: |
15 g, 11 ms duration, 18 shocks |
| EN 61000-4-2 electrostatic discharge (ESD): |
4 kV contact discharge, 8 kV air discharge |
| EN 61000-4-3 electromagnetic field: |
10 V/m (80-3000 MHz) |
| EN 61000-4-4 fast transients (burst): |
2 kV power line, 4 kV data line |
| EN 61000-4-5 surge voltage: |
power line: 2 kV (line/earth), 1 kV (line/line), 4 kV data line |
| EN 61000-4-6 Conducted Immunity: |
10 V (150 kHz-80 MHz) |
| EN 55022: |
EN 55022 Class A |
| FCC CFR47 Part 15: |
FCC 47CFR Part 15, Class A |
| Safety of industrial control equipment: |
cUL 508 |
| Safety of information technology equipment: |
cUL 60950-1 |
| Guarantee: |
60 months (please refer to the terms of guarantee for detailed information) |
| Accessories to Order Separately: |
Fast Ethernet SFP modules, Gigabit Ethernet SFP modules, autoConfiguration Adapter ACA21-USB, terminal cable, Industrial Hivision Network Management software |
| Scope of delivery: |
MACH100 device, terminal block for signal contact, 2 brackets with fasteningscrews (pre-assembled), housing feet - stick-on, non-heating appliance cable - Euro model |
| updat and Revision: |
Revision Number: 0.168 Revision Date: 06-18-2024 |
| Item # |
Type |
| 942003001 |
MACH104-20TX-F |
德國赫思曼hirschmann自動化和控制有限公司是自動化通訊領域的***，產品線從以太網、快速以太網、千兆以太網和萬兆以太網的網絡設備擴展到了應用于不同現場總線系統的光纖接口以及電子執行器和傳感器連接器。防護等級：IP30
目前赫思曼自動化控制有限公司是以太網市場上***一家能夠提供完整數據通信產品的公司。赫思曼hirschmann以太網解決方案為客戶提供了一個統一的企業通信架構，而無需擔心不同的接口或介質問題。
未來以太網和現場總線在用于控制器層的同時，也可隨需應變的應用于現場級的工業網絡中。因此赫思曼hirschmann為現場總線系統如Profibus、Modbus或Geniusbus提供了光纖接口，由于光纖技術的可靠性，這些接口將非常適合使用在現場控制中。
連接器產品線包括用于執行器和傳感器的連接器，以及工業機械工具及設備制造用的連接器。另外，特殊的線纜連接技術在節省時間的同時也節約了開銷。
作為自動化技術的***，赫思曼的許多設計都是具有革新性的，這些方案能夠充分滿足客戶在性能、效率和投資可靠性方面的要求。作為IAONA（工業自動化開放網絡聯盟）組織的創始人之一，赫思曼在以太網技術的確立和在工業領域的標準化上扮演了主要的角色。EPSG（以太網Powerlink標準化組織）倡導的Powerlink已提供了一個開放的平臺，可以通過以太網實現硬實時的應用，例如機器人控制等。赫思曼也是EPSG的創始人之一。
德國赫思曼hirschmann自動化控制有限公司在德國、匈牙利建有生產基地，在許多歐洲國家、美國和亞洲都設立了分支機構。
