| Technical data | KL3362 |
|---|---|
| Number of inputs | 2 analog, 1 trigger |
| Power supply | via the K-bus |
| Signal voltage | -10…+10 V |
| Technology | high-speed data logger |
| Internal resistance | > 500 kΩ |
| Internal resistance E1-GND, E2-GND | > 500 kΩ |
| Supply voltage | – |
| Conversion time | < 100 µs, configurable (10 µs with fast sampling mode) |
| Resolution | 14 bit + sign |
| Measurement error/ uncertainty | < ±0.5 % (relative to full scale value) |
| Internal memory | 32 kbytes |
| Trigger | configurable |
| Current consumption power contacts | – (no power contacts) |
| Current consumption K-bus | typ. 120 mA |
| Bit width in the process image | input/output: 2 x 16 bit data (2 x 8 bit control/status per channel) |
| Special features | high-speed analog analysis |
| Weight | approx. 55 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, UL, ATEX, IECEx |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Ex marking | ATEX: II 3 G Ex nA IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
| Housing data | KL-12-8pin | KS-12-8pin |
|---|---|---|
| Design form | compact terminal housing with signal LEDs | terminal housing with pluggable wiring level |
| Material | polycarbonate | |
| Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm | |
| Installation | on 35 mm DIN rail, conforming to EN 60715 with lock | |
| Side by side mounting by means of | double slot and key connection | |
| Marking | labeling of the BZxxx series | |
| Wiring | solid conductor (e), flexible conductor (f) and ferrule (a): spring actuation by screwdriver | |
| Connection cross-section | s*: 0.08…2.5 mm², st*: 0.08…2.5 mm², f*: 0.14…1.5 mm² |
s*: 0.08…1.5 mm², st*: 0.08…1.5 mm², f*: 0.14…1.5 mm² |
| Connection cross-section AWG | s*: AWG 28…14, st*: AWG 28…14, f*: AWG 26…16 |
s*: AWG 28…16, st*: AWG 28…16, f*: AWG 26…16 |
| Stripping length | 8…9 mm | 9…10 mm |
| Current load power contacts | Imax: 10 A | |
