• Designed to prevent Coldflow, see CMP Technical document TS001 (available upon request)
• -60°C to +130°C
• Class I Zone 1, 21 ａnd Zone 2, 22 Class I Division 2 ABCD
• Globally marked, IECEx, ATEX & cCSAus
• Superior EMC performance
Note: † Grooved Cone (X) is predominantly used for Wire Braid (e.g. GSWB, TCWB), Steel Tape Armour (STA, DSTA) ａnd Aluminium Strip Armour (ASA) but is also suitable for Single Wire Armour (SWA), Aluminium Wire Armour (AWA) ａnd Pliable Wire Armour (PWA) if the range is outside that of the Stepped Cone (W).
Note: Grooved Cone (X) dimensions shown in the Cable Gland Selection Table below are for a double wire strand of braid armour cables. Tapes can also be doubled over. For cables that have only a single layer of armour such as SWA the clamping range should be used as shown in the table below.
CERTIFICATES
PRODUCT SELECTION TABLE
CLICK HERE TO VIEW HOW TO ORDER
Cable Gland Size
Available Entry Threads ＇C＇ (Alternate Metric Thread Lengths Available)
Cable
Bedding
Diameter
＇A＇
Overall
Cable
Diameter
＇B＇
Armour Range †
Grooved Cone (X)
Across
Flats
＇D＇
Across
Corners
＇D＇
Protrusion
Length ＇F＇
Combined Ordering Reference
(*Brass Metric)
Shroud
Cable
Gland
Weight
(Kgs)
Standard
Option
Metric
Thread Length (Metric) ＇E＇
NPT
Thread Length
(NPT) ＇E＇
NPT
Min
Max
Min
Max
Min
Max
Max
Max
Size
Type
Ordering
Suffix
20S16
M20
15.0
½＇
19.9
¾"
3.1
8.6
6.1
13.1
0.3
1.0
24.0
26.4
72.5
20S16
E1FW
1RA
PVC04
0.16
20S
M20
15.0
½＇
19.9
¾"
6.1
11.6
9.5
15.9
0.3
1.0
24.0
26.4
70.0
20S
E1FW
1RA
PVC04
0.15
20
M20
15.0
½＇
19.9
¾"
6.5
13.9
12.5
20.9
0.4
1.0
30.5
33.6
73.0
20
E1FW
1RA
PVC06
0.21
25S
M25
15.0
¾＇
20.2
1"
11.1
19.9
14.0
22.0
0.4
1.2
37.5
41.3
89.0
25S
E1FW
1RA
PVC09
0.33
25
M25
15.0
¾＇
20.2
1"
11.1
19.9
18.2
26.2
0.4
1.2
37.5
41.3
89.0
25
E1FW
1RA
PVC09
0.33
32
M32
15.0
1＇
25.0
1 ¼"
17.0
26.2
23.7
33.9
0.4
1.2
46.0
50.6
86.0
32
E1FW
1RA
PVC11
0.43
40
M40
15.0
1 ¼＇
25.6
1 ½"
22.0
32.1
27.9
40.4
0.4
1.6
55.0
60.5
90.0
40
E1FW
1RA
PVC15
0.62
50S
M50
15.0
1 ½＇
26.1
2"
29.5
38.1
35.2
46.7
0.4
1.6
60.0
66.0
91.0
50S
E1FW
1RA
PVC18
0.75
50
M50
15.0
2＇
26.9
2 ½"
35.6
44.0
40.4
53.0
0.6
1.6
70.1
77.1
95.0
50
E1FW
1RA
PVC21
0.95
63S
M63
15.0
2＇
26.9
2 ½"
40.1
49.9
45.6
59.4
0.6
1.6
75.0
82.5
102.0
63S
E1FW
1RA
PVC23
1.34
63
M63
15.0
2 ½＇
39.9
3"
47.2
55.9
54.6
65.8
0.6
1.6
80.0
88.0
104.0
63
E1FW
1RA
PVC25
1.34
75S
M75
15.0
2 ½＇
39.9
3"
52.8
61.9
59.0
72.0
0.6
1.6
90.0
99.0
115.0
75S
E1FW
1RA
PVC28
2.11
75
M75
15.0
3＇
41.5
3 ½"
59.1
67.9
66.7
78.4
0.6
1.6
100.0
110.0
117.0
75
E1FW
1RA
PVC30
2.42
90
M90
24.0
3 ½＇
42.8
4"
66.6
78.6
76.2
90.3
0.8
1.6
114.3
125.4
147.0
90
E1FW
1RA
PVC32
4.21
100
M100
24.0
3 ½＇
42.8
4"
76.0
90.9
86.1
101.4
0.8
1.6
123.0
135.3
140.0
100
E1FW
1RA
LSF33
4.45
115
M115
24.0
4"
44.0
5"
86.0
97.9
101.5
110.2
0.8
1.6
133.4
146.7
162.0
115
E1FW
1RA
LSF34
6.19
130
M130
24.0
5"
46.8
-
97.0
114.9
110.2
123.2
0.8
1.6
152.4
167.6
174.0
130
E1FW
1RA
LSF35
8.34
Dimensions displayed in millimeters unless otherwise stated
TECHNICAL ILLUSTRATION
