測量原理：放射線測量



特點/應用

Compact transmitter for extreme process conditions (temperature, pressure);

Non-contact measuring technique



界面測量

Interfaces liquid / liquid also with emulsion layers

Interfaces liquid / solid



特點

Heartbeat Technology,

SIL 2/3 according to IEC 61508,

Bluetooth® commissioning, operation and maintenance with the SmartBlue App



電源/通信

2-wire loop powered



測量精度

+/-1%



環(huán)境溫度

-40 °C...+80 °C,

(-40 °F...+176 °F)



過程溫度

Any



過程壓力（絕壓）/***大過壓限定值

Any



主要接液部件

Non-contact



過程連接

Non-contact



傳感器長度

PVT scintillator

400 mm...3000 mm,

>3000 mm cascade mode



***大測量距離

Unlimited measuring range,

Cascade



通信

4...20 mA HART



證書和認證

ATEX, IEC Ex, CSA C/US, NEPSI, INMETRO, EAC Ex, JPN Ex, KC Ex



安全認證

Overfill protection WHG

SIL 2/3



設計認證

EN 10204-3.1



選項

Display



組件

Isotope: FSG60, FSG61,

Source container: FQG60, FQG61, FQG62, FQG63, FQG66,

Mounting accessories: FHG61
